DetorqueJet-3

HEBERLEIN. DETORQUEJET-3.

Features and Benefits.

The DetorqueJet-3 is a highly compact jet without moveable parts. The jet is placed after the set heater and before the third delivery shaft and can be used for both S and Z textured yarns.

1	Torque in textured yarn
2	Torque-free / twist-free yarn

Technical data.

Application area

Type	Count [dtex]
21-3	20 … 167
22-3	167 … 330

All specifications are non-binding reference values.

Air consumption

Type	Air channel diameter	Formula
21-3	2 x 0.7 mm	q_vn = 0.43 x (p_e + 1)
22-3	2 x 1.0 mm	q_vn = 0.86 x (p_e + 1)

p_e= overpressure [bar]q_vn= air consumption per thread [m³/h] (standard conditions according to DIN1343)

Compressed air requirements

Overpressure

0.5 … 2.5 bar

For the compressed air quality requirements, see Compressed air purity.
