FDY-Jet-SP

HEBERLEIN. FDY-JET-SP.

Features and Benefits.

A cost-effective interlacing jet for an application range up to max. 190 dtex. The connector is compatible with all jet packs from the PolyJet-SP-2 series. This ensures maximum flexibility. If requirements change, only the jet packs need to be exchanged.

Technical data.

Application area

Type	Count in jet	Winding speed	Yarn tension after the jet
FJ13.1	… 190 dtex	… 5000 m/min	0.1 … 0.2 cN/dtex

All specifications are non-binding reference values.

Air consumption

Type	Air channel diameter	Formula
FJ13.1	1.3 mm	q_vn = 0.786 x (p_e + 1)

p_e= overpressure [bar]q_vn= air consumption per thread [m³/h] (standard conditions according to DIN1343)

Compressed air requirement

FDY-Jet-SP overpressure

1.0 … 4.0 bar

For the compressed air quality requirements, see Compressed air purity.
