The PolyJet-TG-2 allows different jets types to be easily changed, enabling a rapid response to shifting market trends. The product range covers various requirements for interlacing characteristics. The universal holder ensures durability and robustness.
HEBERLEIN. POLYJET-TG-2 / POLYJET-TG-2 MIGRA.
Assortment.
Series HN
The proven PolyJet-TG-2 HN ensures improved fault-free package build and smooth package unwinding during the subsequent process.
Series HN TopAir
The additional air streams of the PolyJet-TG-2 TopAir induce a large number of uniform and strong interlacing knots. At the same time, air consumption is reduced, as a large count can be processed. Alternatively, optimum performance is achieved at a lower working air pressure. The additional air streams provide for very gentle interlacing.
Series PP
The PolyJet-TG-2 PP allows gentle interlacing with soft interlacing knots. The jet offers a particularly high degree of uniformity at low air pressure.
Series Migra
The PolyJet-TG-2 ensures effective migration of the spinning preparation right into the yarn core.
Technical data.
Application area
|
| Important note |
PolyJet-TG-2
| Type | Count in | Winding | Yarn tension |
|---|---|---|---|
| Series HN | |||
| HN251A/CN33 | 400 … 800 | … 5000 | 0.06 … 0.15 |
| HN321A/CN41 | 550 … 1200 | … 3000 | 0.06 … 0.15 |
| HN403A/CN52 | 1000 … 2500 | … 5000 | 0.06 … 0.15 |
| HN453A/CN63 | 1800 … 4000 | … 3000 | 0.06 … 0.15 |
| Series HN TopAir | |||
| HN251A/CO33 | 400 … 1000 | … 5000 | 0.06 … 0.15 |
| HN321A/CO41 | 550 … 1500 | ~ 5000 | 0.06 … 0.15 |
| HN403A/CO52 | 1000 … 3000 | … 6000 | 0.06 … 0.15 |
| HN453A/CO63 | 1800 … 4500 | … 6000 | 0.06 … 0.15 |
| HN452A/CO62 | 2200 … 5500 | … 6000 | 0.06 … 0.15 |
| HN520A/CO65 | 3000 … 6500 | … 5000 | 0.06 … 0.15 |
| Series PP | |||
| PP1000 | … 600 | … 4000 | 0.06 … 0.15 |
| PP1600 | … 900 | … 4000 | 0.06 … 0.15 |
| PP2400 | … 1500 | … 5000 | 0.06 … 0.15 |
| PP3500 | … 2500 | … 5000 | 0.06 … 0.15 |
| PP5000 | … 3500 | … 5000 | 0.06 … 0.15 |
PolyJet-TG- 2 Migra
| Flat yarns | ||
|---|---|---|
| Type | Count in jet [dtex] | Winding speed [m/min] |
| M320/CN52 | … 5500 | … 6500 |
| M400/CN62 | … 10000 | … 6500 |
| BCF yarns | ||
|---|---|---|
| Type | Count in jet [dtex] | Winding speed [m/min] |
| M320/CN52 | … 8500 | … 5000 |
| M400/CN62 | … 16000 | … 3000 |
Air consumption per thread
PolyJet-TG-2
| Type | Air channel diameter | Formula |
|---|---|---|
| Series HN | ||
| HN251A/CN33 | 2.5 mm | qvn = 2.905 x (pe + 1) |
| HN321A/CN41 | 3.2 mm | qvn = 4.759 x (pe + 1) |
| HN403A/CN52 | 4.0 mm | qvn = 7.437 x (pe + 1) |
| HN453A/CN63 | 4.5 mm | qvn = 9,412 x (pe + 1) |
| Series HN TopAir | ||
| HN251A/CO33 | 2.8 mm | qvn = 3.617 x (pe + 1) |
| HN321A/CO41 | 3.6 mm | qvn = 5.925 x (pe + 1) |
| HN403A/CO52 | 4.5 mm | qvn = 9.285 x (pe + 1) |
| HN453A/CO63 | 5.0 mm | qvn = 11.646 x (pe + 1) |
| HN452A/CO62 | 5.0 mm | qvn = 11.792 x (pe + 1) |
| HN520A/CO65 | 5.9 mm | qvn = 15.754 x (pe + 1) |
| Series PP | ||
| PP1000 | 2.3 mm | qvn = 2.380 x (pe + 1) |
| PP1600 | 2.8 mm | qvn = 3.718 x (pe + 1) |
| PP2400 | 3.4 mm | qvn = 5.354 x (pe + 1) |
| PP3500 | 4.2 mm | qvn = 8.366 x (pe + 1) |
| PP5000 | 5.2 mm | qvn = 12,726 x (pe + 1) |
PolyJet-TG-2 Migra
| Type | Air channel diameter | Formula |
|---|---|---|
M320/CN52 | 3.2 mm | qvn = 4.759 x (pe + 1) |
M400/CN62 | 4.0 mm | qvn = 7,437 x (pe + 1) |
Compressed air requirements
| Overpressure PolyJet-TG-2 | 1.5 … 8.0 bar |
| Overpressure PolyJet-TG-2 Migra | 0.5 … 2.0 bar |
For the compressed air quality requirements, see Compressed air purity.
Request operating instructions.
Would you like to receive an operating manual for your product? Request now.
