HEBERLEIN. SLIDEJET-2T.

Features and Benefits Technical data
Print Back to the product overview

Features and Benefits.

The SlideJet-2T was specially developed for DTY systems with modified (two-in-one) winding stations. The jet is a modular system with a universal quick-lock housing and various easily replaceable jet inserts with two yarn channels.

Technical data.

Application area

Type

Typical range [dtex]

(Max. limits of application)

P141-2T

… 50

(… 67)

P142-2T

… 78

(… 110)

P143-2T

78 … 110

(50 … 167)

All specifications are non-binding reference values.

Air consumption

Type

Air channel diameter *

Formula *

P141-2

0.88 mm

qvn = 0.360 x (pe + 1)

P142-2

1.1 mm

qvn = 0.562 x (pe + 1)

P143-2

1.24 mm

qvn = 0.712 x (pe + 1)
* Specifications apply for 1 threadpe = overpressure [bar]qvn = air consumption per thread [m3/h] (standard conditions according to DIN1343)

Compressed air requirements

Overpressure

0.5 … 6.0 bar

For the compressed air quality requirements, see Compressed air purity.
