The TexJet-ATY produces superior yarn at high processing speeds. It is used for the production of very fine to coarse yarns made of polyester, polyamide, and polypropylene and in the production of high-grade flame and effect yarns.
HEBERLEIN. TEXJET-ATY.
Assortment.
Series Dx0
For voluminous yarns, technical applications, and fashion.
Series Dx1
Is used for producing microfibre, effect, and flame yarns. Possible end products include sportswear, leisurewear, and sewing yarns.
Series Dx2
Highly suited to sportswear, leisurewear, automotive, and technical yarns.
Series Dx3
For extremely compact yarns, automotive, and household textiles.
Series Dx4
For fashion, sportswear, leisurewear, and household textiles.
Series Dxx St
For glass filament yarns.
Technical data.
Application area
| Type | Total count of feed [dtex] | Single filament counts | Max. overfeed | Winding speed |
|---|---|---|---|---|
| Series Dx0 – For bulky yarns and high overfeed | ||||
| D40 | 330 … 1100 | 0.8 … 5.5 | … 160 % | … 600 |
| D50 | 600 … 2500 | 4.0 … 12.0 | … 160 % | … 600 |
| D60 | 1800 … 3500 | 4.0 … 12.0 | … 160 % | … 500 |
| D70 | 2500 … 4500 | 4.0 … 12.0 | … 160 % | … 500 |
| Series Dx1 – For more volume, covering capacity, overfeed and higher texturing speed | ||||
| D11 | 60 … 250 | 0.5 … 2.5 | … 70 % | … 1200 |
| D21 | 200 … 450 | 0.5 … 2.5 | … 70 % | … 1000 |
| D41 | 330 … 800 | 0.5 … 2.5 | … 60 % | … 900 |
| Series Dx2 – For compact, particularly stable yarns with small, tight loops | ||||
| D002 | 10 … 50 | 0.5 … 1.5 | … 60 % | … 400 |
| D02 | 44 … 90 | 0.5 … 1.5 | … 40 % | … 800 |
| D12 | 80 … 250 | 0.8 … 3.5 | … 60 % | … 1000 |
| D22 | 150 … 480 | 0.8 … 3.5 | … 60 % | … 900 |
| D32 | 330 … 800 | 0.8 … 5.5 | … 60 % | … 800 |
| D42 | 600 … 1100 | 0.8 … 5.5 | … 60 % | … 800 |
| D52 | 600 … 2500 | 4.0 … 12.0 | … 50 % | … 800 |
| D62 | 1800 … 3500 | 4.0 … 12.0 | … 40 % | … 600 |
| Series Dx3 – For extremely compact, highly stable yarns | ||||
| D03 | 44 … 90 | 0.5 … 1.5 | … 40 % | … 700 |
| D13 | 80 … 250 | 0.8 … 3.5 | … 50 % | … 700 |
| D23 | 150 … 480 | 0.8 … 3.5 | … 50 % | … 700 |
| D33 | 330 … 800 | 0.8 … 5.5 | … 50 % | … 700 |
| D43 | 660 … 1100 | 0.8 … 5.5 | … 50 % | … 700 |
| Series Dx4 – For effect yarns | ||||
| D14 | 60 … 250 | 0.5 … 2.5 | … 70 % | … 700 |
| D24 | 150 … 480 | 0.8 … 3.5 | … 70 % | … 700 |
| D34 | 330 … 800 | 0.8 … 5.5 | … 70 % | … 700 |
| D44 | 600 … 1100 | 0.8 … 5.5 | … 70 % | … 700 |
| Applications with polypropylene yarns (PP) | ||||
| D42 | 150 … 480 | 3.0 … 8.0 | … 30 % | … 500 |
| D52 | 350 … 1100 | 3.0 … 8.0 | … 30 % | … 500 |
| D62 | 800 … 2200 | 3.0 … 8.0 | … 30 % | … 500 |
| D70 | 1200 … 3500 | 3.0 … 8.0 | … 30 % | … 500 |
| Series Dxx St – for glass filament yarns | ||||
| D70 St | 1360 … 25000 | 4.0 … 17.0 µm | ||
Air consumption per thread
| Type | Air channel diameter | Formula |
|---|---|---|
| D002 | 3 x 0.40 mm | qvn = 0.26 x (pe + 1) |
| D02, D03 | 3 x 0.50 mm | qvn = 0.37 x (pe + 1) |
| D11, D12, D13 | 3 x 0.60 mm | qvn = 0.54 x (pe + 1) |
| D14 | 1 x 0.90 mm | qvn = 0.40 x (pe + 1) |
| D21, D22, D23 | 3 x 0.75 mm | qvn = 0.81 x (pe + 1) |
| D24 | 1 x 1.15 mm | qvn = 0.60 x (pe + 1) |
| D32, D33 | 3 x 0.90 mm | qvn = 1.21 x (pe + 1) |
| D34 | 1 x 1.30 mm | qvn = 0.90 x (pe + 1) |
| D40, D41, D42, D43 | 3 x 1.00 mm | qvn = 1.46 x (pe + 1) |
| D44 | 1 x 1.50 mm | qvn = 1.10 x (pe + 1) |
| D50, D52 | 3 x 1.20 mm | qvn = 2.05 x (pe + 1) |
| D60 | 3 x 1.35 mm | qvn = 2.56 x (pe + 1) |
| D62 | 3 x 1.40 mm | qvn = 2.75 x (pe + 1) |
| D70 | 3 x 1.60 mm | qvn = 3.59 x (pe + 1) |
| D70 St | 3 x 1.70 mm | qvn = 4.03 x (pe + 1) |
Compressed air requirements
| Overpressure | 7.0 … 14.0 bar ** |
For the compressed air quality requirements, see Compressed air purity.
